Hide-A-Way®
Trailer Side Lift

Lifting Capacity – 4,500 lbs

• Floor Heights:
48” Laden to 58” Unladen

• Designed to Reduce
Road Calls

LPS Standard Features Benefits
True Level Ride Lift Gate
Provides a Safer Working Environment for Driver and Freight
Galvanized Gate and Primary Platform, Aluminum secondary Platform & Single Retention Ramp
Prevents Rust
Power In and Out with Stainless Steel Chain
Designed to Reduce Road Calls
Flashing Safety Light on End of Platform
Safety Feature Provides Greater Visibility of Gate
Automatic Over-the-Road Lock
Safely Secures Lift Gate in Over-the-Road Position
Adjustable to Trailer Dimensions
Ensures Custom Fit for Side Lift Gate
Accommodates Curb or Street Side of Trailer Installation
Flexibility to Meet Your Specific Delivery Requirements
Power Pack Enclosure
Houses Pump, Motor, and Room for up to Four (4) Batteries*
Pressure Compensated Flow Control
Steady Hydraulic Pressure for Smooth Operation
Gravity Down
Reduces Power Usage and Motor Wear
Marine Potted Switches
Watertight Switches – Reduces Electrical Failure
Spring Assisted Opening and Closing
Ease of Use and Reduces Physical Effort to Operate
Maintenance Minder2
Measures and Records Lift Gate Operating Data
Model Number Lifting Capacity Platform Size Main Platform Secondary Platform Ramp Vehicle Width Approximate Weight

LPS 4500

4,500 lbs

72"Wx68"D
80"Wx76"D

72"Wx51.5"D
80"Wx51.5"D

72"Wx17"D
80"Wx25"D

15" Deep
Retention
Single/Dual

96" and 102"

1,650 lbs
2,200 lbs

Option Number OPtion Description

111

Additional Circuit Breaker for Supply Line

133

Conversion Kit For Mounting to Aluminum Cross Members

134

Mud Flap

142

Dual Power Unit

154

Reflecting Tape

155

High Visibility Flashing Safety Lights along Lift Gate Arm, Nose Warning Light

261

Emergency Hand Pump

265

Power Unit Box Work Light

268

Collapsible Safety Hand Rails

270LPS-R1

1 Piece Retention Ramp Option for LPS

270LPS-R2

2 Piece Retention Ramp Option for LPS

271

Plug-In, Hand-Held Remote with Storage Box in Place of Upper Switch

GV

Galvanized (Full Gate)

P46622

AGM Battery

Option Number Option Description

257-NG-30

Power Kit: 30' “2” Gauge Cable – Dual Pole with Combo Box (Dual/Single Pole Receptacles)

257-NG-45

Power Kit: 45' “2” Gauge Cable – Dual Pole with Combo Box (Dual/Single Pole Receptacles)

257-NG-60

Power Kit: 60' “2” Gauge Cable – Dual Pole with Combo Box (Dual/Single Pole Receptacles)

269-2B

Battery Hold-Down Kit - 2 Batteries for 42, 48, 60, 72, 80 Gate Width

269-3B

Battery Hold-Down Kit - 3 Batteries for 60, 72, 80 Gate Width

269-4B

Battery Hold-Down Kit - 4 Batteries for 72, 80 Gate Width

Contact us for more information:
